The CX FLEXY 433 CX TOP is a smart and versatile control unit designed for the automation of swing gates, sliding gates, and rolling shutters. It supports two 230 V single-phase motors for gate applications or one 230 V motor for rolling shutters, with flexible 230 V / 120 V power supply options. The unit features programmable operating logic via an integrated display menu, inputs for push-buttons, keyswitches, safety photocells, safety edges, and open/close limit switches, ensuring safe and reliable operation. An integrated 433.92 MHz radio receiver allows storage of up to 240 personal pass transmitters, while display monitoring provides real-time input status. Additional features include courtesy light and 24 V flashing light outputs, pre-opening safety device testing, adjustable motor power and operating time, an RJ45 connector for connection to the PROG2 programmer, and full compliance with EU standby ecodesign regulation 2023/826.
Access the full technical manual here to explore detailed specifications, installation guidance, and maintenance instructions. CX FLEXY 433
